| TECHNICAL POSSIBILITIES OF ZAKŁAD MECHANICZNY "MESTIL" IN SCOPE OF PRODUCTION OF SPARE PARTS AND SUBASSEMBLIES |
||
| 1. MCV 1000 QUICK -średnica toczenia od 10 do 500 mm -długość toczenia L = 2500 mm 2. CNC - UNIVERSAL TURNING MACHINES - diameter of turning max. 250 mm - length of turning max. L = 800 mm |
 |
|
| 3. CNC - TURNING MACHINE type Famot 400 (Gildemeister) with Siemens control system - 500 mm dia. of turning - 640 mm length of turning 4. UNIVERSAL TURNING MACHINE TUJ-50M - dia. of turning 560 mm - length of turning L = 4.000 mm |
 |
|
| 5. UNIVERSAL CENVENTIONAL MILLING MACHINES Working Scope - Length max. 850 mm - Width 280 mm - Height 430 mm 6. CNC UNIVERSAL MILLING MACHINES Working Scope - Length max. 800 mm - Width 500 mm - Height 400 mm |
 |
|
| 7. MILLING MACHINES a) CNC type FP5ATNC355 (prod.Deckel) - machining scope 710x660x500 mm - table surface 520x820 mm b) hand steering - machining scope 1120x345x400 mm 8. CNC DRILLING BORING AND MILLING MACHINE DMU60E, 2x MAHO MH 500C - (Firma Deckel-Maho) - working scope 600x525x500 mm - table area 900x543 mm |
 |
|
| 9. SPECIAL MILLING MACHINE for milling of rolling tooth wheels - milling module max.m = 6 - diameter max. 500 mm 10. GRINDING MACHINES for shafts - diameter max. 250 mm - length max. L = 2500 mm |
 |
|
| 11. GRINDING MACHINES for planes - grinding length max. L = 1000 mm - width max. 300 mm 12. GRINDING MACHINES for opennings - diameter of grinding 10 to 200 mm - length of grinding L max. = 200 mm 13. GRINDING MACHNES coaxial "LKDs" (prod. Deckel) - working scope 400x250x340 mm |
||
|
|
||
| 15. ELECTROEROSION MACHINES: a) CNC "Roboform 200" sinking depth (prod. Charmilles) - machining scope 320x220x320 mm - table surface 560x400 mm b) wire outcutting machine type "Robofil 290" (prod. Charmilles) - machining scope 400x250x200 mm - table surface 900x600 mm c) wire outcutting machine type "SCX2" CNC (prod. China) - machining scope 150x150x60 mm |
 |
|
| 16. SHEARING MACHINE type NG -13 - length of cutting 3000 mm - sheet max. thickness 13 mm 17. SLOTTING MACHINE - slide jump 0 -160 mm - distance from knife base to stand 360 mm 18. SHEET ROLLING MACHINE FOR 15 mm sheet thickness type PV5S - rolling length 3150 mm, min. dia.400 mm |
 |
|
| 19. ECCENTRIC AND HYDRAULIC PRESS -16 tons, 20 tons, 40 tons, 160 tons 20. HARDENING OVENS - max. dimensions for carbonizing - length 900 mm - width 500 mm - height 400 mm |
 |
|
| 21. Coaxial measuring machine "MITUTOYO FJ805", measuring with use "GEOPAK 5.00" and "SCANPAK - 3" programs, work area: 800x550x450 mm 22. Device for plasma cutting PA-S45W, Made by Kjellberg Company, with equipment to burning the propane - oxygen mix. Technical data: - Numerical control with use ESSI program, - Thickness of cutting: for 1 up to 140 mm, - Work area: 2000x5500 mm |
 |
|
